Brixlegg Railway & Bus Station

Brixlegg Railway & Bus Station

Tyrol, Austria

CLIENT:

Austrian Federal Railways

PERIOD:

2012 - 2015

BRIEF DESCRIPTION:

BRIXLEGG GOES MULTI-MODAL
Brixlegg is located in the Lower Inn Valley, at the foot of the Alpbachtal, in Tyrol, Austria, with a population of roughly 2000. The Brixlegg Station is a multi-modal public transport hub, whose main attraction via public transportation is the arrival of visitors for the yearly Forum Alpbach, in the neighboring town of Alpbach.
The principal design scheme of the Brixlegg station is its underlying grid, spanning 2,20 × 2.20m throughout the whole station, on which architectural elements are scaled. As needed, the grid network is extendable and multiplicative, providing the ease of a later expansion or insertion of new architectural elements within a logical framework.

TEAM:
Markus Ostertag, Les Jordan, Aida Knoettig, Daniel Cranach, Thomas Burghardt

3D DEVELOPMENT: Alexander Diebalek
STRUCTURAL ENGINEERING: Passegger-Autengruber ZT-GmbH
RAIL PLANNING / URBAN PLANNING: Bernard Ingenieure ZT GmbH
ELECTRICAL ENGINEERING: A3-Jenewein Ingenieurbüro GmbH
MECHANICAL / PLUMBING ENGINEERING: ZPLAN Haustechnik GmbH

DATA:
Construction Cost:
Train Station: appr.19.5 Million Euros
Station Square, including Bus Facilities: 1.4 Million Euros
Park & Ride Facility: appr. 660,000 Euros

Completion of 2,600m new railway tracks
New subterranean passageway for urban connection and barrier-free platform access
Complete renovation below and above ground level
New elevator access to platform island (barrier-free)
New platform island: length 320m, height from rails 55cm – stepless access to trains
Covered waiting areas on platforms
Seating areas
Orientation systems and signage, including provisions for the blind
Information monitors

Train arrivals per day: 80
Passenger Frequency: Over 1,500 passengers per day
Park & Ride Facility with 125 Parking Spaces
Bike & Ride Facility with 60 Bicycle Parking Spaces
New Circular Driveway for Regional Buses
3 Taxi Parking Spaces

SERVICES:

Preliminary Design, Design Development, Construction Documents & Permitting, Tender Documents

SITE PLAN

SITE PLAN

LONGITUDINAL SECTION

LONGITUDINAL SECTION
